HF – Helical Parallel-Shaft Gearboxes for hoisting

Hoist Drives

HF Series are the new range of application-based products, been designed and developed after a detailed study of many equipments operating in real time. Design of HF series have been framed by our synergetic R&D team, after conducting several interactions and meeting with many Crane manufacturer to understand, the know-how of the application, challenges faced by crane manufacturers and the needs for special design features during operation of the equipment.

Specifications

Torque range
Up to 5,900 Nm

Main options
External Brake Version

Gear ratios
Up to 114.40

Max radial force
Up to 30,600 N

Mounting options
H2 (Default), H1, H3 & H4

Operation
M5, M6 & M7
Output
Solid Spline WOA Connection flange
Input
Input with e-motor coupling,
Size
P90 to P160
Motors Brake Motor,
4 Pole, 50 Hz, S1/S4 Duty

CATALOGUE

NÁHRADNÍ DÍLY

PROSPEKT


52 stran 1.1 MB	40 stran 2 MB					48 stran 5.8 MB
