HOME PRODUKTY MOBILNÍ POHONY TRASMITAL BONFIGLIOLI 700 TK  Slew drives 700 TW 700 CK 700 C 700 TK 700 FW     Slew drives for excavator duty The 700TK series is the compact and yet powerful package for the slew drive of excavators up to approx. 20 ton class. The units are powered by integrated axial piston hydraulic motors, developed in cooperation with KAYABA and can be accommodated within the smallest space. Wide choice of drive pinions, standard or to customer specs.   Torque Range 750 ... 9.000 Nm Excavator weight 1,5 to 20 ton. Gear Ratios 7 ... 40 Key Features Flange mounted Output shaft with integral pinion Rugged construction High torque capacity Output shafts supported by heavy duty bearings Compact design Hydraulic motors KAYABA hydraulic motor fixed displacement complete with shockless type pressure relief valve Motor options Anti swing-back valve Brake Hydraulically released failsafe parking brake Brake retarder valve on request BROCHURE TECHNICAL DATA - 12 pages 3 MB pages 2 364 KB pages 1 77 KB 66 pages 2,1 MB 44 pages 2,5 MB
