Motor type
Reversible synchronous
Ambient temperature operation
C
-15...+55
Ambient temperature storage
-20...+100
Thermal class
120
Motor speed
rpm
1000 @ 50 Hz
Mounting
any position
Standard motor voltages
V
24, 110, 220 (others on request)
HVT
2.0 KV (motor voltage>40V) or 0.6 KV (motor voltage<40V) for 1 min.
Weight
gm
1250
Temperature rise over ambient
80 max.
Rotor shaft
Steel, ground and polished
Bearings
Ball Bearing
External dimensions
sqr 64 x 146 mm
